VG STUDIO MAX
· Porosity Inspection · Nominal/Actual Comparison between CAD and CT · Coordinate Measurement · Wall Thickness Analysis
Contact SalesVGSTUDIO MAX
Main features -Tomography image and 3D modeling verification -Tomographic image measurement -3D dimension precision measurement (dimension tolerance applied) -Bubble / foreign matter defect analysis -Nominal/real data comparison
Features
·CT reconstruction -CT reconstruction module for reconstructing 3D volume data sets using images taken with a CT scanner
·Geometry Analyses -Coordinate Measurement Module for measurements on even the most difficult-to-access surfaces of a component. -CAD Import Module for the import of native CAD files such as CATIA V5 and Creo/Pro/ ENGINEER. -CAD Import with PMI Module for the additional import of Product and Manufacturing Information (PMI). -Nominal/Actual Comparison Module for the comparison of manufactured parts with CAD, mesh, or other voxel data. -Wall Thickness Analysis Module for the localization of insufficient or excessive wall thickness or gap width. -Manufacturing Geometry Correction Module for the correction of tools for injection molding or casting and 3D printing geometries. -Reverse Engineering Module for the conversion of CT scans into CAD models that can be used in CAD systems.
·Material Analyses -Porosity/Inclusion Analysis Module for the non-destructive defect discovery in castings, including prediction of pore cuts. -Extended Porosity/Inclusion Analysis Module for defect analysis according to specifications P 202 and P 201.
